Render View for ParaView. More...
#include <vtkPVRenderView.h>
Public Types | |
| enum | InteractionModes { INTERACTION_MODE_UNINTIALIZED = -1, INTERACTION_MODE_3D = 0, INTERACTION_MODE_2D, INTERACTION_MODE_SELECTION, INTERACTION_MODE_ZOOM, INTERACTION_MODE_POLYGON } |
| enum | { DEFAULT_RENDERER = 0, NON_COMPOSITED_RENDERER = 1 } |
| Defines various renderer types. More... | |
| enum | BackgroundMode { DEFAULT, GRADIENT, IMAGE, SKYBOX, STEREO_SKYBOX } |
| enum | GenericFilmicPresets { Custom = 0, Default = 1, Uncharted2 = 2 } |
| Defines tone mapping generic filmic presets. More... | |
| typedef vtkPVView | Superclass |
 Public Types inherited from vtkPVView | |
| typedef vtkView | Superclass |
| Public Types inherited from vtkView | |
| typedef vtkObject | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) override |
| virtual vtkRenderer * | GetRenderer (int rendererType=DEFAULT_RENDERER) |
| Returns the renderer given an int identifying its type. More... | |
| vtkRenderWindowInteractor * | GetInteractor () |
| Returns the interactor. More... | |
| virtual void | SetupInteractor (vtkRenderWindowInteractor *) |
| Set the interactor. More... | |
| void | StillRender () override |
| Triggers a high-resolution render. More... | |
| void | InteractiveRender () override |
| Triggers a interactive render. More... | |
| void | ConfigureCompressor (const char *configuration) |
| Passes the compressor configuration to the client-server synchronizer, if any. More... | |
| virtual void | ResetCameraClippingRange () |
| Resets the clipping range. More... | |
| void | InvalidateCachedSelection () |
| Invalidates cached selection. More... | |
| void | SetMaxClipBounds (double bds[6]) |
| Used by Cinema to enforce a consistent depth scaling. More... | |
| virtual void | SetGridAxes3DActor (vtkPVGridAxes3DActor *) |
| Set the vtkPVGridAxes3DActor to use for the view. More... | |
| virtual void | SetLegendGridActor (vtkLegendScaleActor *) |
| Set the vtkLegendScaleActor to use for the view. More... | |
| virtual void | SetPolarGridActor (vtkPolarAxesActor2D *) |
| Set the vtkPolarAxesActor to use for the view. More... | |
| virtual void | SetCenterAxesVisibility (bool) |
| Forwarded to center axes. More... | |
| void | SetParallelProjection (int mode) |
| Forward to vtkCamera. More... | |
| virtual void | SynchronizeGeometryBounds () |
| Synchronizes bounds information on all nodes and reset camera clipping planes. More... | |
| void | Update () override |
| Overridden to synchronize information among processes whenever data changes. More... | |
| virtual void | UpdateLOD () |
| Asks representations to update their LOD geometries. More... | |
| int | GetDataDistributionMode (bool low_res) |
| Returns the data distribution mode to use. More... | |
| void | Deliver (int use_lod, unsigned int size, unsigned int *representation_ids) override |
| Called on all processes to request data-delivery for the list of representations. More... | |
| bool | GetUseOrderedCompositing () |
| Returns true when ordered compositing is needed on the current group of processes. More... | |
| bool | GetRenderEmptyImages () |
| Returns true when the compositor should not use the empty images optimization. More... | |
| void | CopyViewUpdateOptions (vtkPVRenderView *otherView) |
| Copy internal fields that are used for rendering decision such as remote/local rendering, composite and so on. More... | |
| bool | GetOSPRayContinueStreaming () |
| Has OSPRay reached the max frames? More... | |
| void | SetOSPRayRendererType (std::string) |
| Set the OSPRay renderer to use. More... | |
| virtual void | SetMaterialLibrary (vtkPVMaterialLibrary *) |
| For OSPRay, set the library of materials. More... | |
| void | SetViewTime (double value) override |
| Get/Set the time this view is showing. More... | |
| virtual vtkRenderViewBase * | GetRenderView () |
| void | ScaleRendererViewports (const double viewport[4]) override |
| Overridden to scale the OrientationWidget appropriately. More... | |
| void | SynchronizeMaximumIds (vtkIdType *maxPointId, vtkIdType *maxCellId) |
| This is used by vtkPVHardwareSelector to synchronize element ids between all ranks involved in selection. More... | |
| void | SetHardwareSelector (vtkPVHardwareSelector *selector) |
| virtual void | SetInteractionMode (int mode) |
| Get/Set the interaction mode. More... | |
| virtual int | GetInteractionMode () |
| Get/Set the interaction mode. More... | |
| void | SetSize (int, int) override |
| Overridden to call InvalidateCachedSelection() whenever the render window parameters change. More... | |
| void | SetPosition (int, int) override |
| Overridden to call InvalidateCachedSelection() whenever the render window parameters change. More... | |
| virtual vtkRenderer * | GetNonCompositedRenderer () |
| Gets the non-composited renderer for this view. More... | |
| vtkCamera * | GetActiveCamera () |
| Get/Set the active camera. More... | |
| virtual void | SetActiveCamera (vtkCamera *) |
| Get/Set the active camera. More... | |
| virtual vtkPVInteractorStyle * | GetInteractorStyle () |
| Returns the interactor style. More... | |
| void | ResetCamera () |
| Resets the active camera using collective prop-bounds. More... | |
| void | ResetCamera (double bounds[6]) |
| Resets the active camera using collective prop-bounds. More... | |
| void | ResetCameraScreenSpace (double offsetRatio=0.9) |
| Resets the active camera using collective prop-bounds. More... | |
| void | ResetCameraScreenSpace (double *bounds, double offsetRatio=0.9) |
| Resets the active camera using collective prop-bounds. More... | |
| virtual void | SetSuppressRendering (bool) |
| SuppressRendering can be used to suppress the render within a StillRender or InteractiveRender. More... | |
| virtual bool | GetSuppressRendering () |
| SuppressRendering can be used to suppress the render within a StillRender or InteractiveRender. More... | |
| virtual void | SuppressRenderingOn () |
| SuppressRendering can be used to suppress the render within a StillRender or InteractiveRender. More... | |
| virtual void | SuppressRenderingOff () |
| SuppressRendering can be used to suppress the render within a StillRender or InteractiveRender. More... | |
| virtual void | SetStillRenderImageReductionFactor (int) |
| Get/Set the reduction-factor to use when for StillRender(). More... | |
| virtual int | GetStillRenderImageReductionFactor () |
| Get/Set the reduction-factor to use when for StillRender(). More... | |
| virtual void | SetInteractiveRenderImageReductionFactor (int) |
| Get/Set the reduction-factor to use when for InteractiveRender(). More... | |
| virtual int | GetInteractiveRenderImageReductionFactor () |
| Get/Set the reduction-factor to use when for InteractiveRender(). More... | |
| virtual void | SetRemoteRenderingThreshold (double) |
| Get/Set the data-size in megabytes above which remote-rendering should be used, if possible. More... | |
| virtual double | GetRemoteRenderingThreshold () |
| Get/Set the data-size in megabytes above which remote-rendering should be used, if possible. More... | |
| virtual void | SetLODRenderingThreshold (double) |
| Get/Set the data-size in megabytes above which LOD rendering should be used, if possible. More... | |
| virtual double | GetLODRenderingThreshold () |
| Get/Set the data-size in megabytes above which LOD rendering should be used, if possible. More... | |
| virtual void | SetLODResolution (double) |
| Get/Set the LOD resolution. More... | |
| virtual double | GetLODResolution () |
| Get/Set the LOD resolution. More... | |
| virtual void | SetUseOutlineForLODRendering (bool) |
| When set to true, instead of using simplified geometry for LOD rendering, uses outline, if possible. More... | |
| virtual bool | GetUseOutlineForLODRendering () |
| When set to true, instead of using simplified geometry for LOD rendering, uses outline, if possible. More... | |
| void | SetUseLightKit (bool enable) |
| Enable/Disable light kit. More... | |
| virtual bool | GetUseLightKit () |
| Enable/Disable light kit. More... | |
| virtual void | UseLightKitOn () |
| Enable/Disable light kit. More... | |
| virtual void | UseLightKitOff () |
| Enable/Disable light kit. More... | |
| void | StreamingUpdate (const double view_planes[24]) |
| void | DeliverStreamedPieces (unsigned int size, unsigned int *representation_ids) |
| void | SelectCells (int region[4], const char *array=nullptr) |
| Make a selection. More... | |
| void | SelectCells (int region0, int region1, int region2, int region3, const char *array=nullptr) |
| Make a selection. More... | |
| void | SelectPoints (int region[4], const char *array=nullptr) |
| Make a selection. More... | |
| void | SelectPoints (int region0, int region1, int region2, int region3, const char *array=nullptr) |
| Make a selection. More... | |
| void | Select (int field_association, int region[4], const char *array=nullptr) |
| Make a selection. More... | |
| void | SelectPolygonPoints (int *polygon2DArray, vtkIdType arrayLen) |
| Make a selection with a polygon. More... | |
| void | SelectPolygonCells (int *polygon2DArray, vtkIdType arrayLen) |
| Make a selection with a polygon. More... | |
| void | SelectPolygon (int field_association, int *polygon2DArray, vtkIdType arrayLen) |
| Make a selection with a polygon. More... | |
| virtual vtkSelection * | GetLastSelection () |
| Provides access to the last selection. More... | |
| virtual void | SetUseInteractiveRenderingForScreenshots (bool) |
| Set or get whether capture should be done as StillRender or InteractiveRender when capturing screenshots. More... | |
| virtual void | UseInteractiveRenderingForScreenshotsOn () |
| Set or get whether capture should be done as StillRender or InteractiveRender when capturing screenshots. More... | |
| virtual void | UseInteractiveRenderingForScreenshotsOff () |
| Set or get whether capture should be done as StillRender or InteractiveRender when capturing screenshots. More... | |
| virtual bool | GetUseInteractiveRenderingForScreenshots () |
| Set or get whether capture should be done as StillRender or InteractiveRender when capturing screenshots. More... | |
| virtual bool | GetRemoteRenderingAvailable () |
| Returns if remote-rendering is possible on the current group of processes. More... | |
| void | RemoteRenderingAvailableOff () |
| Returns if remote-rendering is possible on the current group of processes. More... | |
| void | NVPipeAvailableOn () |
| Determine if NVPipe is an available compressor option. More... | |
| void | NVPipeAvailableOff () |
| Determine if NVPipe is an available compressor option. More... | |
| virtual bool | GetUsedLODForLastRender () |
| Returns true if the most recent render used LOD. More... | |
| void | SetLockBounds (bool nv) |
| Used by Cinema to enforce a consistent viewpoint and depth scaling. More... | |
| virtual bool | GetLockBounds () |
| Used by Cinema to enforce a consistent viewpoint and depth scaling. More... | |
| int | RegisterPropForHardwareSelection (vtkPVDataRepresentation *repr, vtkProp *prop) |
| Representations that support hardware (render-buffer based) selection, should register the prop that they use for selection rendering. More... | |
| void | UnRegisterPropForHardwareSelection (vtkPVDataRepresentation *repr, vtkProp *prop) |
| Representations that support hardware (render-buffer based) selection, should register the prop that they use for selection rendering. More... | |
| void | SetShowAnnotation (bool val) |
| Enable/disable showing of annotation for developers. More... | |
| virtual void | SetUpdateAnnotation (bool) |
| Enable/disable showing of annotation for developers. More... | |
| void | SetAnnotationColor (double r, double g, double b) |
| Set color of annotation text for developers. More... | |
| virtual void | SetOrientationAxesInteractivity (bool) |
| Forwarded to orientation axes widget. More... | |
| virtual void | SetOrientationAxesVisibility (bool) |
| Forwarded to orientation axes widget. More... | |
| void | SetOrientationAxesLabelColor (double r, double g, double b) |
| Forwarded to orientation axes widget. More... | |
| void | SetOrientationAxesOutlineColor (double r, double g, double b) |
| Forwarded to orientation axes widget. More... | |
| void | SetOrientationAxesXColor (double r, double g, double b) |
| Forwarded to orientation axes widget. More... | |
| void | SetOrientationAxesYColor (double r, double g, double b) |
| Forwarded to orientation axes widget. More... | |
| void | SetOrientationAxesZColor (double r, double g, double b) |
| Forwarded to orientation axes widget. More... | |
| void | SetOrientationAxesXVisibility (bool vis) |
| Forwarded to orientation axes widget. More... | |
| void | SetOrientationAxesYVisibility (bool vis) |
| Forwarded to orientation axes widget. More... | |
| void | SetOrientationAxesZVisibility (bool vis) |
| Forwarded to orientation axes widget. More... | |
| void | SetOrientationAxesXLabelText (const char *text) |
| Forwarded to orientation axes widget. More... | |
| void | SetOrientationAxesYLabelText (const char *text) |
| Forwarded to orientation axes widget. More... | |
| void | SetOrientationAxesZLabelText (const char *text) |
| Forwarded to orientation axes widget. More... | |
| void | SetCameraOrientationWidgetVisibility (bool visible) |
| Forwarded to camera orientation widget. More... | |
| void | SetCameraOrientationWidgetSize (int size) |
| Forwarded to camera orientation widget. More... | |
| void | SetCameraOrientationWidgetPadding (int padding[2]) |
| Forwarded to camera orientation widget. More... | |
| void | SetCameraOrientationWidgetAnchor (int anchor) |
| Forwarded to camera orientation widget. More... | |
| virtual void | SetCenterOfRotation (double x, double y, double z) |
| Forward to vtkPVInteractorStyle instances. More... | |
| virtual void | SetRotationFactor (double factor) |
| Forward to vtkPVInteractorStyle instances. More... | |
| void | SetKeyLightWarmth (double val) |
| Forward to vtkLightKit. More... | |
| void | SetKeyLightIntensity (double val) |
| Forward to vtkLightKit. More... | |
| void | SetKeyLightElevation (double val) |
| Forward to vtkLightKit. More... | |
| void | SetKeyLightAzimuth (double val) |
| Forward to vtkLightKit. More... | |
| void | SetFillLightWarmth (double val) |
| Forward to vtkLightKit. More... | |
| void | SetKeyToFillRatio (double val) |
| Forward to vtkLightKit. More... | |
| void | SetFillLightElevation (double val) |
| Forward to vtkLightKit. More... | |
| void | SetFillLightAzimuth (double val) |
| Forward to vtkLightKit. More... | |
| void | SetBackLightWarmth (double val) |
| Forward to vtkLightKit. More... | |
| void | SetKeyToBackRatio (double val) |
| Forward to vtkLightKit. More... | |
| void | SetBackLightElevation (double val) |
| Forward to vtkLightKit. More... | |
| void | SetBackLightAzimuth (double val) |
| Forward to vtkLightKit. More... | |
| void | SetHeadLightWarmth (double val) |
| Forward to vtkLightKit. More... | |
| void | SetKeyToHeadRatio (double val) |
| Forward to vtkLightKit. More... | |
| void | SetMaintainLuminance (int val) |
| Forward to vtkLightKit. More... | |
| virtual void | SetUseHiddenLineRemoval (bool) |
| Forward to 3D renderer. More... | |
| virtual void | SetUseDepthPeeling (int val) |
| Forward to 3D renderer. More... | |
| virtual void | SetUseDepthPeelingForVolumes (bool val) |
| Forward to 3D renderer. More... | |
| virtual void | SetMaximumNumberOfPeels (int val) |
| Forward to 3D renderer. More... | |
| virtual void | SetBackgroundTexture (vtkTexture *val) |
| Forward to 3D renderer. More... | |
| virtual void | SetUseRenderViewSettingsForBackground (bool) |
| When set, background color and mode will be obtained from vtkPVRenderViewSettings. More... | |
| virtual bool | GetUseRenderViewSettingsForBackground () |
| When set, background color and mode will be obtained from vtkPVRenderViewSettings. More... | |
| virtual void | SetBackgroundColorMode (int) |
| API for background color selection. More... | |
| virtual void | SetBackground (double, double, double) |
| API for background color selection. More... | |
| virtual void | SetBackground (double [3]) |
| API for background color selection. More... | |
| virtual double * | GetBackground () |
| API for background color selection. More... | |
| virtual void | GetBackground (double &, double &, double &) |
| API for background color selection. More... | |
| virtual void | GetBackground (double [3]) |
| API for background color selection. More... | |
| virtual void | SetBackground2 (double, double, double) |
| API for background color selection. More... | |
| virtual void | SetBackground2 (double [3]) |
| API for background color selection. More... | |
| virtual double * | GetBackground2 () |
| API for background color selection. More... | |
| virtual void | GetBackground2 (double &, double &, double &) |
| API for background color selection. More... | |
| virtual void | GetBackground2 (double [3]) |
| API for background color selection. More... | |
| virtual void | SetUseEnvironmentLighting (bool) |
| API for background color selection. More... | |
| virtual void | SetEnvironmentalBG (double r, double g, double b) |
| Entry point for environmental backgrounds. More... | |
| virtual void | SetEnvironmentalBG2 (double r, double g, double b) |
| Entry point for environmental backgrounds. More... | |
| virtual void | SetEnvironmentalBGTexture (vtkTexture *val) |
| Entry point for environmental backgrounds. More... | |
| virtual void | SetGradientEnvironmentalBG (int val) |
| Entry point for environmental backgrounds. More... | |
| virtual void | SetTexturedEnvironmentalBG (int val) |
| Entry point for environmental backgrounds. More... | |
| virtual void | SetBackgroundMode (int val) |
| Entry point for environmental backgrounds. More... | |
| void | AddLight (vtkLight *) |
| Entry point for dynamic lights. More... | |
| void | RemoveLight (vtkLight *) |
| Entry point for dynamic lights. More... | |
| void | SetStereoCapableWindow (int val) |
| Forward to vtkRenderWindow. More... | |
| void | SetStereoRender (int val) |
| Forward to vtkRenderWindow. More... | |
| virtual void | SetStereoType (int) |
| Forward to vtkRenderWindow. More... | |
| virtual void | SetServerStereoType (int) |
| Forward to vtkRenderWindow. More... | |
| void | SetMultiSamples (int val) |
| Forward to vtkRenderWindow. More... | |
| void | SetAlphaBitPlanes (int val) |
| Forward to vtkRenderWindow. More... | |
| void | SetStencilCapable (int val) |
| Forward to vtkRenderWindow. More... | |
| virtual void | SetCamera2DManipulators (const int manipulators[9]) |
| Forwarded to vtkPVInteractorStyle if present on local processes. More... | |
| virtual void | SetCamera3DManipulators (const int manipulators[9]) |
| Forwarded to vtkPVInteractorStyle if present on local processes. More... | |
| void | SetCameraManipulators (vtkPVInteractorStyle *style, const int manipulators[9]) |
| Forwarded to vtkPVInteractorStyle if present on local processes. More... | |
| virtual void | SetReverseMouseWheelZoomDirection (bool reverse) |
| Forwarded to vtkPVInteractorStyle if present on local processes. More... | |
| virtual void | SetMouseWheelZoomsToCursor (bool value) |
| Forwarded to vtkPVInteractorStyle if present on local processes. More... | |
| virtual void | SetCamera2DMouseWheelMotionFactor (double factor) |
| Forwarded to vtkPVInteractorStyle if present on local processes. More... | |
| virtual void | SetCamera3DMouseWheelMotionFactor (double factor) |
| Forwarded to vtkPVInteractorStyle if present on local processes. More... | |
| virtual bool | GetUseLODForInteractiveRender () |
| Returns whether the view will use LOD rendering for the next InteractiveRender() call based on the geometry sizes determined by the most recent call to Update(). More... | |
| virtual bool | GetUseDistributedRenderingForRender () |
| Returns whether the view will use distributed rendering for the next full-resolution render. More... | |
| virtual bool | GetUseDistributedRenderingForLODRender () |
| Returns whether the view will use distributed rendering for the next low-resolution render. More... | |
| virtual vtkTypeUInt32 | GetStillRenderProcesses () |
| Returns the processes (vtkPVSession::ServerFlags) that are to be involved in the next StillRender() call based on the decisions made during the most recent Update(). More... | |
| virtual vtkTypeUInt32 | GetInteractiveRenderProcesses () |
| Returns the processes (vtkPVSession::ServerFlags) that are to be involved in the next InteractiveRender() call based on the decisions made during the most recent Update() and UpdateLOD(). More... | |
| virtual void | SetUseFXAA (bool) |
| Enable/disable FXAA antialiasing. More... | |
| virtual bool | GetUseFXAA () |
| Enable/disable FXAA antialiasing. More... | |
| void | SetFXAARelativeContrastThreshold (double val) |
| FXAA tunable parameters. More... | |
| void | SetFXAAHardContrastThreshold (double val) |
| FXAA tunable parameters. More... | |
| void | SetFXAASubpixelBlendLimit (double val) |
| FXAA tunable parameters. More... | |
| void | SetFXAASubpixelContrastThreshold (double val) |
| FXAA tunable parameters. More... | |
| void | SetFXAAUseHighQualityEndpoints (bool val) |
| FXAA tunable parameters. More... | |
| void | SetFXAAEndpointSearchIterations (int val) |
| FXAA tunable parameters. More... | |
| void | SetUseToneMapping (bool v) |
| Tone Mapping options. More... | |
| virtual bool | GetUseToneMapping () |
| Tone Mapping options. More... | |
| void | SetToneMappingType (int) |
| Tone Mapping options. More... | |
| void | SetExposure (double) |
| Tone Mapping options. More... | |
| void | SetContrast (double) |
| Tone Mapping options. More... | |
| void | SetShoulder (double) |
| Tone Mapping options. More... | |
| void | SetMidIn (double) |
| Tone Mapping options. More... | |
| void | SetMidOut (double) |
| Tone Mapping options. More... | |
| void | SetHdrMax (double) |
| Tone Mapping options. More... | |
| void | SetUseACES (bool) |
| Tone Mapping options. More... | |
| void | SetGenericFilmicPresets (int t) |
| Tone Mapping options. More... | |
| virtual void | SetUseSSAO (bool) |
| SSAO options. More... | |
| virtual bool | GetUseSSAO () |
| SSAO options. More... | |
| virtual void | SetUseSSAODefaultPresets (bool) |
| SSAO options. More... | |
| virtual void | SetRadius (double) |
| SSAO options. More... | |
| virtual void | SetKernelSize (int) |
| SSAO options. More... | |
| virtual void | SetBias (double) |
| SSAO options. More... | |
| virtual void | SetBlur (bool) |
| SSAO options. More... | |
| void | AddPropToRenderer (vtkProp *prop) |
| Add props directly to the view. More... | |
| void | RemovePropFromRenderer (vtkProp *prop) |
| Add props directly to the view. More... | |
| bool | BeginValuePassForRendering (int fieldAssociation, const char *arrayName, int component) |
| Experimental API to grab re-colorable images. More... | |
| void | EndValuePassForRendering () |
| Experimental API to grab re-colorable images. More... | |
| vtkSmartPointer< vtkFloatArray > | GrabValuePassResult () |
| Experimental API to grab re-colorable images. More... | |
| void | CaptureZBuffer () |
| Access to the Z buffer. More... | |
| vtkFloatArray * | GetCapturedZBuffer () |
| Access to the Z buffer. More... | |
| void | SetEnableOSPRay (bool) |
| Switches between rasterization and ray tracing. More... | |
| bool | GetEnableOSPRay () |
| Switches between rasterization and ray tracing. More... | |
| void | SetShadows (bool) |
| Controls whether OSPRay sends casts shadow rays or not. More... | |
| bool | GetShadows () |
| Controls whether OSPRay sends casts shadow rays or not. More... | |
| void | SetAmbientOcclusionSamples (int) |
| Sets the number of occlusion query rays that OSPRay sends at each intersection. More... | |
| int | GetAmbientOcclusionSamples () |
| Sets the number of occlusion query rays that OSPRay sends at each intersection. More... | |
| void | SetRouletteDepth (int) |
| Sets the depth of monte carlo samples on the path tracer. More... | |
| int | GetRouletteDepth () |
| Sets the depth of monte carlo samples on the path tracer. More... | |
| void | SetSamplesPerPixel (int) |
| Set the number of primary rays that OSPRay shoots per pixel. More... | |
| int | GetSamplesPerPixel () |
| Set the number of primary rays that OSPRay shoots per pixel. More... | |
| void | SetMaxFrames (int) |
| Set the number of render passes OSPRay takes to accumulate subsampled color results. More... | |
| int | GetMaxFrames () |
| Set the number of render passes OSPRay takes to accumulate subsampled color results. More... | |
| void | SetDenoise (bool) |
| Controls whether to use image denoising to improve appearance. More... | |
| bool | GetDenoise () |
| Controls whether to use image denoising to improve appearance. More... | |
| void | SetLightScale (double) |
| Dimish or Amplify all lights in the scene. More... | |
| double | GetLightScale () |
| Dimish or Amplify all lights in the scene. More... | |
| void | SetBackgroundNorth (double x, double y, double z) |
| Control of background orientation for OSPRay. More... | |
| void | SetBackgroundEast (double x, double y, double z) |
| Control of background orientation for OSPRay. More... | |
| void | SetTimeCacheSize (int) |
| Set the size of OSPRay's temporal cache. More... | |
| int | GetTimeCacheSize () |
| Set the size of OSPRay's temporal cache. More... | |
| Public Member Functions inherited from vtkPVView | |
| void | PrintSelf (ostream &os, vtkIndent indent) override |
| virtual void | SetPPI (int) |
| Description: Set the screen PPI. More... | |
| virtual int | GetPPI () |
| virtual bool | GetViewTimeValid () |
| Get ViewTimeValid. More... | |
| void | Update () override |
| Overridden to not call Update() directly on the input representations, instead use ProcessViewRequest() for all vtkPVDataRepresentations. More... | |
| bool | InTileDisplayMode () |
| Returns true if the application is currently in tile display mode. More... | |
| bool | InCaveDisplayMode () |
| Returns true if the application is currently in cave/immersive display mode. More... | |
| bool | GetLocalProcessSupportsInteraction () |
| Returns true if the local process can support interaction. More... | |
| vtkRenderWindow * | GetRenderWindow () |
| If this view needs a render window (not all views may use one), this method can be used to get the render window associated with this view on the current process. More... | |
| vtkMTimeType | GetUpdateTimeStamp () |
| Provides access to the time when Update() was last called. More... | |
| virtual bool | IsCached (vtkPVDataRepresentation *) |
Called in vtkPVDataRepresentation::ProcessViewRequest to check if the representation already has cached data. More... | |
| virtual void | ClearCache (vtkPVDataRepresentation *) |
Called by vtkPVDataRepresentation whenever vtkPVDataRepresentation::MarkModified is called. More... | |
| virtual int * | GetPosition () |
| Set the position on this view in the multiview configuration. More... | |
| virtual void | GetPosition (int &, int &) |
| Set the position on this view in the multiview configuration. More... | |
| virtual void | GetPosition (int [2]) |
| Set the position on this view in the multiview configuration. More... | |
| virtual int * | GetSize () |
| Set the size of this view in the multiview configuration. More... | |
| virtual void | GetSize (int &, int &) |
| Set the size of this view in the multiview configuration. More... | |
| virtual void | GetSize (int [2]) |
| Set the size of this view in the multiview configuration. More... | |
| virtual double | GetViewTime () |
| Get/Set the time this view is showing. More... | |
| virtual void | SetCacheKey (double) |
| Get/Set the cache key. More... | |
| virtual double | GetCacheKey () |
| Get/Set the cache key. More... | |
| virtual void | SetUseCache (bool) |
| Get/Set whether caching is enabled. More... | |
| virtual bool | GetUseCache () |
| Get/Set whether caching is enabled. More... | |
| virtual void | PrepareForScreenshot () |
| These methods are used to setup the view for capturing screen shots. More... | |
| virtual void | CleanupAfterScreenshot () |
| These methods are used to setup the view for capturing screen shots. More... | |
| void | SetTileScale (int x, int y) |
| When saving screenshots with tiling, these methods get called. More... | |
| void | SetTileViewport (double x0, double y0, double x1, double y1) |
| When saving screenshots with tiling, these methods get called. More... | |
| virtual void | SetLogName (const std::string &name) |
| This is solely intended to simplify debugging and use for any other purpose is vehemently discouraged. More... | |
| const std::string & | GetLogName () const |
| This is solely intended to simplify debugging and use for any other purpose is vehemently discouraged. More... | |
| void | SetDeliveryManager (vtkPVDataDeliveryManager *) |
| Provides access to data delivery & cache manager for this view. More... | |
| virtual vtkPVDataDeliveryManager * | GetDeliveryManager () |
| Provides access to data delivery & cache manager for this view. More... | |
| Public Member Functions inherited from vtkView | |
| vtkView * | NewInstance () const |
| void | AddRepresentation (vtkDataRepresentation *rep) |
| void | SetRepresentation (vtkDataRepresentation *rep) |
| vtkDataRepresentation * | AddRepresentationFromInputConnection (vtkAlgorithmOutput *conn) |
| vtkDataRepresentation * | SetRepresentationFromInputConnection (vtkAlgorithmOutput *conn) |
| vtkDataRepresentation * | AddRepresentationFromInput (vtkDataObject *input) |
| vtkDataRepresentation * | SetRepresentationFromInput (vtkDataObject *input) |
| void | RemoveRepresentation (vtkDataRepresentation *rep) |
| void | RemoveRepresentation (vtkAlgorithmOutput *rep) |
| void | RemoveAllRepresentations () |
| int | GetNumberOfRepresentations () |
| vtkDataRepresentation * | GetRepresentation (int index=0) |
| bool | IsRepresentationPresent (vtkDataRepresentation *rep) |
| virtual void | ApplyViewTheme (vtkViewTheme *vtkNotUsed(theme)) |
| vtkCommand * | GetObserver () |
| void | RegisterProgress (vtkObject *algorithm, const char *message=NULL) |
| void | UnRegisterProgress (vtkObject *algorithm) |
| Public Member Functions inherited from vtkObject | |
| vtkBaseTypeMacro (vtkObject, vtkObjectBase) | |
| virtual void | DebugOn () |
| virtual void | DebugOff () |
| bool | GetDebug () |
| void | SetDebug (bool debugFlag) |
| virtual void | Modified () |
| virtual vtkMTimeType | GetMTime () |
| void | RemoveObserver (unsigned long tag) |
| void | RemoveObservers (unsigned long event) |
| void | RemoveObservers (const char *event) |
| void | RemoveAllObservers () |
| int | HasObserver (unsigned long event) |
| int | HasObserver (const char *event) |
| int | InvokeEvent (unsigned long event) |
| int | InvokeEvent (const char *event) |
| unsigned long | AddObserver (unsigned long event, vtkCommand *, float priority=0.0f) |
| unsigned long | AddObserver (const char *event, vtkCommand *, float priority=0.0f) |
| vtkCommand * | GetCommand (unsigned long tag) |
| void | RemoveObserver (vtkCommand *) |
| void | RemoveObservers (unsigned long event, vtkCommand *) |
| void | RemoveObservers (const char *event, vtkCommand *) |
| int | HasObserver (unsigned long event, vtkCommand *) |
| int | HasObserver (const char *event, vtkCommand *) |
| unsigned long | AddObserver (unsigned long event, U observer, void(T::*callback)(), float priority=0.0f) |
| unsigned long | AddObserver (unsigned long event, U observer, void(T::*callback)(vtkObject *, unsigned long, void *), float priority=0.0f) |
| unsigned long | AddObserver (unsigned long event, U observer, bool(T::*callback)(vtkObject *, unsigned long, void *), float priority=0.0f) |
| int | InvokeEvent (unsigned long event, void *callData) |
| int | InvokeEvent (const char *event, void *callData) |
| unsigned long | AddObserver (unsigned long event, vtkCommand *, float priority=0.0f) |
| unsigned long | AddObserver (const char *event, vtkCommand *, float priority=0.0f) |
| vtkCommand * | GetCommand (unsigned long tag) |
| void | RemoveObserver (vtkCommand *) |
| void | RemoveObservers (unsigned long event, vtkCommand *) |
| void | RemoveObservers (const char *event, vtkCommand *) |
| int | HasObserver (unsigned long event, vtkCommand *) |
| int | HasObserver (const char *event, vtkCommand *) |
| unsigned long | AddObserver (unsigned long event, U observer, void(T::*callback)(), float priority=0.0f) |
| unsigned long | AddObserver (unsigned long event, U observer, void(T::*callback)(vtkObject *, unsigned long, void *), float priority=0.0f) |
| unsigned long | AddObserver (unsigned long event, U observer, bool(T::*callback)(vtkObject *, unsigned long, void *), float priority=0.0f) |
| int | InvokeEvent (unsigned long event, void *callData) |
| int | InvokeEvent (const char *event, void *callData) |
| Public Member Functions inherited from vtkObjectBase | |
| const char * | GetClassName () const |
| virtual void | Delete () |
| virtual void | FastDelete () |
| void | Print (ostream &os) |
| virtual void | Register (vtkObjectBase *o) |
| virtual void | UnRegister (vtkObjectBase *o) |
| void | SetReferenceCount (int) |
| virtual void | PrintHeader (ostream &os, vtkIndent indent) |
| virtual void | PrintTrailer (ostream &os, vtkIndent indent) |
| int | GetReferenceCount () |
| void | PrintRevisions (ostream &) |
| virtual void | PrintHeader (ostream &os, vtkIndent indent) |
| virtual void | PrintTrailer (ostream &os, vtkIndent indent) |
| int | GetReferenceCount () |
| void | PrintRevisions (ostream &) |
Static Public Member Functions | |
| static vtkPVRenderView * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkPVRenderView * | SafeDownCast (vtkObject *o) |
| static vtkInformationIntegerKey * | USE_LOD () |
| USE_LOD indicates if LOD is being used for the current render/update. More... | |
| static vtkInformationDoubleKey * | LOD_RESOLUTION () |
| Indicates the LOD resolution in REQUEST_UPDATE_LOD() pass. More... | |
| static vtkInformationIntegerKey * | USE_OUTLINE_FOR_LOD () |
| Indicates the LOD must use outline if possible in REQUEST_UPDATE_LOD() pass. More... | |
| static vtkInformationIntegerKey * | RENDER_EMPTY_IMAGES () |
| Representation can publish this key in their REQUEST_INFORMATION() pass to indicate that the representation needs to disable IceT's empty image optimization. More... | |
| static vtkInformationIntegerKey * | NEED_ORDERED_COMPOSITING () |
| Representation can publish this key in their REQUEST_INFORMATION() pass to indicate that the representation needs ordered compositing. More... | |
| static vtkInformationDoubleVectorKey * | VIEW_PLANES () |
| Key used to pass meta-data about the view frustum in REQUEST_STREAMING_UPDATE() pass. More... | |
| static vtkInformationRequestKey * | REQUEST_STREAMING_UPDATE () |
| Streaming pass request. More... | |
| static vtkInformationRequestKey * | REQUEST_PROCESS_STREAMED_PIECE () |
| Pass to relay the streamed "piece" to the representations. More... | |
| static void | SetDeliverToAllProcesses (vtkInformation *info, vtkPVDataRepresentation *repr, bool clone) |
Requests the view to deliver the pieces produced by the repr to all processes after a gather to the root node to merge the datasets generated by each process. More... | |
| static void | SetDeliverToClientAndRenderingProcesses (vtkInformation *info, vtkPVDataRepresentation *repr, bool deliver_to_client, bool gather_before_delivery, int port=0) |
| Requests the view to deliver the data to the client always. More... | |
| static vtkAlgorithmOutput * | GetPieceProducer (vtkInformation *info, vtkPVDataRepresentation *repr, int port=0) |
| Convenience methods used by representations to pass represented data. More... | |
| static vtkAlgorithmOutput * | GetPieceProducerLOD (vtkInformation *info, vtkPVDataRepresentation *repr, int port=0) |
| Convenience methods used by representations to pass represented data. More... | |
| static void | SetRedistributionMode (vtkInformation *info, vtkPVDataRepresentation *repr, int mode, int port=0) |
| Convenience methods used by representations to pass represented data. More... | |
| static void | SetRedistributionModeToSplitBoundaryCells (vtkInformation *info, vtkPVDataRepresentation *repr, int port=0) |
| Convenience methods used by representations to pass represented data. More... | |
| static void | SetRedistributionModeToDuplicateBoundaryCells (vtkInformation *info, vtkPVDataRepresentation *repr, int port=0) |
| Convenience methods used by representations to pass represented data. More... | |
| static void | SetRedistributionModeToUniquelyAssignBoundaryCells (vtkInformation *info, vtkPVDataRepresentation *repr, int port=0) |
| Convenience methods used by representations to pass represented data. More... | |
| static void | SetGeometryBounds (vtkInformation *info, vtkPVDataRepresentation *repr, const double bounds[6], vtkMatrix4x4 *transform=nullptr, int port=0) |
| Convenience methods used by representations to pass represented data. More... | |
| static void | SetStreamable (vtkInformation *info, vtkPVDataRepresentation *repr, bool streamable) |
| Convenience methods used by representations to pass represented data. More... | |
| static void | SetNextStreamedPiece (vtkInformation *info, vtkPVDataRepresentation *repr, vtkDataObject *piece) |
| Convenience methods used by representations to pass represented data. More... | |
| static vtkDataObject * | GetCurrentStreamedPiece (vtkInformation *info, vtkPVDataRepresentation *repr) |
| Convenience methods used by representations to pass represented data. More... | |
| static void | SetRequiresDistributedRendering (vtkInformation *info, vtkPVDataRepresentation *repr, bool value, bool for_lod=false) |
| Some representation only work when remote rendering or local rendering. More... | |
| static void | SetRequiresDistributedRenderingLOD (vtkInformation *info, vtkPVDataRepresentation *repr, bool value) |
| Some representation only work when remote rendering or local rendering. More... | |
| static vtkPVCameraCollection * | GetDiscreteCameras (vtkInformation *info, vtkPVDataRepresentation *repr) |
| DiscreteCameras are a collection of cameras when specified, forces the view to only interact to a camera in the collection. More... | |
| static void | SetDiscreteCameras (vtkInformation *info, vtkPVDataRepresentation *repr, vtkPVCameraCollection *style) |
| DiscreteCameras are a collection of cameras when specified, forces the view to only interact to a camera in the collection. More... | |
| Static Public Member Functions inherited from vtkPVView | |
| static int | IsTypeOf (const char *type) |
| static vtkPVView * | SafeDownCast (vtkObject *o) |
| static void | SetEnableStreaming (bool) |
| static bool | GetEnableStreaming () |
| static vtkInformationObjectBaseKey * | VIEW () |
| Key used to pass the vtkPVView pointer to the representation during any of the view passes such as REQUEST_UPDATE(), REQUEST_UPDATE_LOD(), REQUEST_RENDER(), etc. More... | |
| static vtkInformationRequestKey * | REQUEST_UPDATE () |
| This is a Update-Data pass. More... | |
| static vtkInformationRequestKey * | REQUEST_UPDATE_LOD () |
| This is a Update-LOD-Data pass. More... | |
| static vtkInformationRequestKey * | REQUEST_RENDER () |
| This is a render pass. More... | |
| static void | SetPiece (vtkInformation *info, vtkPVDataRepresentation *repr, vtkDataObject *data, unsigned long trueSize=0, int port=0) |
| static vtkDataObject * | GetPiece (vtkInformation *info, vtkPVDataRepresentation *repr, int port=0) |
| static vtkDataObject * | GetDeliveredPiece (vtkInformation *info, vtkPVDataRepresentation *repr, int port=0) |
| static void | SetPieceLOD (vtkInformation *info, vtkPVDataRepresentation *repr, vtkDataObject *data, unsigned long trueSize=0, int port=0) |
| static vtkDataObject * | GetPieceLOD (vtkInformation *info, vtkPVDataRepresentation *repr, int port=0) |
| static vtkDataObject * | GetDeliveredPieceLOD (vtkInformation *info, vtkPVDataRepresentation *repr, int port=0) |
| static void | SetUseGenericOpenGLRenderWindow (bool val) |
| Use this to indicate that the process should use vtkGenericOpenGLRenderWindow rather than vtkRenderWindow when creating an new render window. More... | |
| static bool | GetUseGenericOpenGLRenderWindow () |
| Use this to indicate that the process should use vtkGenericOpenGLRenderWindow rather than vtkRenderWindow when creating an new render window. More... | |
| Static Public Member Functions inherited from vtkView | |
| static vtkView * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkView * | SafeDownCast (vtkObjectBase *o) |
| Static Public Member Functions inherited from vtkObject | |
| static vtkObject * | New () |
| static void | BreakOnError () |
| static void | SetGlobalWarningDisplay (int val) |
| static void | GlobalWarningDisplayOn () |
| static void | GlobalWarningDisplayOff () |
| static int | GetGlobalWarningDisplay () |
| static void | SetGlobalWarningDisplay (int val) |
| static void | GlobalWarningDisplayOn () |
| static void | GlobalWarningDisplayOff () |
| static int | GetGlobalWarningDisplay () |
| Static Public Member Functions inherited from vtkObjectBase | |
| static vtkTypeBool | IsTypeOf (const char *name) |
| static vtkObjectBase * | New () |
| static vtkObjectBase * | New () |
Protected Member Functions | |
| vtkPVRenderView () | |
| ~vtkPVRenderView () override | |
| virtual void | Render (bool interactive, bool skip_rendering) |
| Actual render method. More... | |
| virtual void | AboutToRenderOnLocalProcess (bool interactive) |
| Called just before the local process renders. More... | |
| bool | ShouldUseDistributedRendering (double geometry_size, bool using_lod) |
| Returns true if distributed rendering should be used based on the geometry size. More... | |
| bool | ShouldUseLODRendering (double geometry) |
| Returns true if LOD rendering should be used based on the geometry size. More... | |
| bool | IsProcessRenderingGeometriesForCompositing (bool using_distributed_rendering) |
| Returns true if the local process is invovled in rendering composited geometry i.e. More... | |
| void | SetLastSelection (vtkSelection *) |
| Set the last selection object. More... | |
| virtual void | UpdateCenterAxes () |
| UpdateCenterAxes(). More... | |
| bool | GetLocalProcessDoesRendering (bool using_distributed_rendering) |
| Returns true if the local process is doing to do actual render or displaying an image in a viewport. More... | |
| bool | TestCollaborationCounter () |
| In multi-clients mode, ensures that all processes are in the same "state" as far as the view is concerned. More... | |
| void | SynchronizeForCollaboration () |
| Synchronizes remote-rendering related parameters for collaborative rendering in multi-clients mode. More... | |
| virtual void | BuildAnnotationText (ostream &str) |
| Method to build annotation text to annotate the view with runtime information. More... | |
| virtual bool | PrepareSelect (int fieldAssociation, const char *array=nullptr) |
| Prepare for selection. More... | |
| virtual void | PostSelect (vtkSelection *sel, const char *array=nullptr) |
| Post process after selection. More... | |
| virtual void | UpdateBackground (vtkRenderer *renderer=nullptr) |
| Updates background color. More... | |
| void | ConfigureTexture (vtkTexture *texture) |
| Configure texture based on scalar type. More... | |
| virtual void | SetupAndSetRenderer (vtkRenderer *ren) |
| Set the 3D renderer to use within the render view. More... | |
| virtual unsigned int | GetSynchronizationCounter () |
| SynchronizationCounter is used in multi-clients mode to ensure that the views on two different clients are in the same state as the server side. More... | |
| virtual bool | GetMakingSelection () |
| Returns true is currently generating a selection. More... | |
| Protected Member Functions inherited from vtkPVView | |
| vtkPVView (bool create_render_window=true) | |
| ~vtkPVView () override | |
| vtkRenderWindow * | NewRenderWindow () |
| Subclasses should use this method to create new render windows instead of directly creating a new one. More... | |
| void | SetRenderWindow (vtkRenderWindow *) |
| Subclasses can use this method to set the render window created for this view. More... | |
| void | AllReduce (const vtkBoundingBox &source, vtkBoundingBox &dest) |
| Reduce bounding box between all participating processes. More... | |
| void | AllReduce (vtkTypeUInt64 source, vtkTypeUInt64 &dest, int operation, bool skip_data_server=false) |
| Reduce between all participating processes using the operation (vtkCommunicator::StandardOperations) specified. More... | |
| vtkPVSession * | GetSession () |
| virtual bool | GetInCaptureScreenshot () |
Flag set to true between calls to PrepareForScreenshot and CleanupAfterScreenshot. More... | |
| void | SynchronizeRepresentationTemporalPipelineStates () |
| Called in Update() to sync HasTemporalPipeline flags between representations on all processes. More... | |
| void | AddRepresentationInternal (vtkDataRepresentation *rep) override |
| Overridden to assign IDs to each representation. More... | |
| void | RemoveRepresentationInternal (vtkDataRepresentation *rep) override |
| Overridden to assign IDs to each representation. More... | |
| int | CallProcessViewRequest (vtkInformationRequestKey *passType, vtkInformation *request, vtkInformationVector *reply) |
| Subclasses can use this method to trigger a pass on all representations. More... | |
| Protected Member Functions inherited from vtkView | |
| virtual vtkObjectBase * | NewInstanceInternal () const |
| vtkView () | |
| ~vtkView () | |
| virtual vtkDataRepresentation * | CreateDefaultRepresentation (vtkAlgorithmOutput *conn) |
| virtual void | ProcessEvents (vtkObject *caller, unsigned long eventId, void *callData) |
| virtual void | AddRepresentationInternal (vtkDataRepresentation *vtkNotUsed(rep)) |
| virtual void | RemoveRepresentationInternal (vtkDataRepresentation *vtkNotUsed(rep)) |
| virtual void | ProcessEvents (vtkObject *caller, unsigned long eventId, void *callData) |
| virtual void | AddRepresentationInternal (vtkDataRepresentation *vtkNotUsed(rep)) |
| virtual void | RemoveRepresentationInternal (vtkDataRepresentation *vtkNotUsed(rep)) |
| virtual void | SetReuseSingleRepresentation (bool) |
| virtual bool | GetReuseSingleRepresentation () |
| virtual void | ReuseSingleRepresentationOn () |
| virtual void | ReuseSingleRepresentationOff () |
| Protected Member Functions inherited from vtkObject | |
| vtkObject () | |
| virtual | ~vtkObject () |
| void | RegisterInternal (vtkObjectBase *, vtkTypeBool check) VTK_OVERRIDE |
| void | UnRegisterInternal (vtkObjectBase *, vtkTypeBool check) VTK_OVERRIDE |
| void | InternalGrabFocus (vtkCommand *mouseEvents, vtkCommand *keypressEvents=NULL) |
| void | InternalReleaseFocus () |
| void | InternalGrabFocus (vtkCommand *mouseEvents, vtkCommand *keypressEvents=NULL) |
| void | InternalReleaseFocus () |
| Protected Member Functions inherited from vtkObjectBase | |
| vtkObjectBase () | |
| virtual | ~vtkObjectBase () |
| virtual void | CollectRevisions (ostream &) |
| virtual void | ReportReferences (vtkGarbageCollector *) |
| vtkObjectBase (const vtkObjectBase &) | |
| void | operator= (const vtkObjectBase &) |
Additional Inherited Members | |
| Static Protected Member Functions inherited from vtkPVView | |
| static vtkPVDataDeliveryManager * | GetDeliveryManager (vtkInformation *info) |
Render View for ParaView.
vtkRenderView equivalent that is specialized for ParaView. vtkRenderView handles polygonal rendering for ParaView in all the different modes of operation. vtkPVRenderView instance must be created on all involved processes. vtkPVRenderView uses the information about what process it has been created on to decide what part of the "rendering" happens on the process.
Definition at line 64 of file vtkPVRenderView.h.
| typedef vtkPVView vtkPVRenderView::Superclass |
Definition at line 69 of file vtkPVRenderView.h.
| Enumerator | |
|---|---|
| INTERACTION_MODE_UNINTIALIZED | |
| INTERACTION_MODE_3D | |
| INTERACTION_MODE_2D | |
| INTERACTION_MODE_SELECTION | |
| INTERACTION_MODE_ZOOM | |
| INTERACTION_MODE_POLYGON | |
Definition at line 72 of file vtkPVRenderView.h.
| anonymous enum |
Defines various renderer types.
| Enumerator | |
|---|---|
| DEFAULT_RENDERER | |
| NON_COMPOSITED_RENDERER | |
Definition at line 119 of file vtkPVRenderView.h.
| anonymous enum |
OrderedCompositingConfiguration lets representations indicate to the view how the representation participates in data-redistribution necessary when ordered-compositing is being used.
These flags are meant to be combined together using bit-wise-OR.
If not specified, default is 0 i.e. the representation data will be left untouched. Except for trivial representations or representations that have their full rendering geometry available on all rendering ranks, this is not recommended.
DATA_IS_REDISTRIBUTABLE indicates that the view may redistribute the rendering data from this representation as needed. This is typical for representation rendering poly-data or unstructured grids.
USE_DATA_FOR_LOAD_BALANCING indicates that when building a sortable distribution for the data, it should use this representation data. If not set, the representation will not contribute to the algorithm that builds the kd-tree used to split data across rendering ranks.
USE_BOUNDS_FOR_REDISTRIBUTION may be used when the data is too heavy to move (i.e DATA_IS_REDISTRIBUTABLE is not true) and is already split across ranks in a sortable fashion. In that case, this indicates the view must use the spatial partitioning of this representation's data and move other data accordingly. This flag cannot be combined with DATA_IS_REDISTRIBUTABLE or USE_BOUNDS_FOR_REDISTRIBUTION.
| Enumerator | |
|---|---|
| USE_BOUNDS_FOR_REDISTRIBUTION | |
| DATA_IS_REDISTRIBUTABLE | |
| USE_DATA_FOR_LOAD_BALANCING | |
Definition at line 499 of file vtkPVRenderView.h.
| Enumerator | |
|---|---|
| DEFAULT | |
| GRADIENT | |
| IMAGE | |
| SKYBOX | |
| STEREO_SKYBOX | |
Definition at line 708 of file vtkPVRenderView.h.
Defines tone mapping generic filmic presets.
| Enumerator | |
|---|---|
| Custom | |
| Default | |
| Uncharted2 | |
Definition at line 899 of file vtkPVRenderView.h.
|
protected |
|
overrideprotected |
|
static |
|
virtual |
Reimplemented from vtkPVView.
Reimplemented in vtkPVOrthographicSliceView, vtkPVRenderViewWithEDL, and vtkPVMultiSliceView.
Reimplemented from vtkPVView.
Reimplemented in vtkPVOrthographicSliceView, vtkPVRenderViewWithEDL, and vtkPVMultiSliceView.
|
static |
|
overridevirtual |
Reimplemented from vtkView.
Reimplemented in vtkPVRenderViewWithEDL.
|
virtual |
Get/Set the interaction mode.
Default is INTERACTION_MODE_3D. If INTERACTION_MODE_SELECTION is selected, then whenever the user drags and creates a selection region, this class will fire a vtkCommand::SelectionChangedEvent event with the selection region as the argument.
Reimplemented in vtkPVOrthographicSliceView.
|
virtual |
Get/Set the interaction mode.
Default is INTERACTION_MODE_3D. If INTERACTION_MODE_SELECTION is selected, then whenever the user drags and creates a selection region, this class will fire a vtkCommand::SelectionChangedEvent event with the selection region as the argument.
Overridden to call InvalidateCachedSelection() whenever the render window parameters change.
Reimplemented from vtkPVView.
Overridden to call InvalidateCachedSelection() whenever the render window parameters change.
Reimplemented from vtkPVView.
|
virtual |
Gets the non-composited renderer for this view.
This is typically used for labels, 2D annotations etc.
|
virtual |
Returns the renderer given an int identifying its type.
Reimplemented in vtkPVOrthographicSliceView.
| vtkCamera* vtkPVRenderView::GetActiveCamera | ( | ) |
Get/Set the active camera.
The active camera is set on both the composited and non-composited renderer.
|
virtual |
Get/Set the active camera.
The active camera is set on both the composited and non-composited renderer.
| vtkRenderWindowInteractor* vtkPVRenderView::GetInteractor | ( | ) |
Returns the interactor.
|
virtual |
Set the interactor.
Client applications must set the interactor to enable interactivity. Note this method will also change the interactor styles set on the interactor.
Reimplemented in vtkPVOrthographicSliceView.
|
virtual |
Returns the interactor style.
| void vtkPVRenderView::ResetCamera | ( | ) |
Resets the active camera using collective prop-bounds.
OffsetRatio can be used to add a zoom offset.
| void vtkPVRenderView::ResetCamera | ( | double | bounds[6] | ) |
Resets the active camera using collective prop-bounds.
OffsetRatio can be used to add a zoom offset.
| void vtkPVRenderView::ResetCameraScreenSpace | ( | double | offsetRatio = 0.9 | ) |
Resets the active camera using collective prop-bounds.
OffsetRatio can be used to add a zoom offset.
Resets the active camera using collective prop-bounds.
OffsetRatio can be used to add a zoom offset.
| double* vtkPVRenderView::ComputeVisibleBounds | ( | vtkPVDataRepresentation * | pvrepr | ) |
Compute and reduce the visible bounds of the provided representation.
Uses LastRepresentationVisibleBounds to store the result until the next call.
|
overridevirtual |
Triggers a high-resolution render.
this->GetStillRenderProcesses(). Implements vtkPVView.
|
overridevirtual |
Triggers a interactive render.
Based on the settings on the view, this may result in a low-resolution rendering or a simplified geometry rendering.
this->GetInteractiveRenderProcesses(). Implements vtkPVView.
|
virtual |
SuppressRendering can be used to suppress the render within a StillRender or InteractiveRender.
This is useful in cases where you want the representations mappers to be setup for rendering and have their data ready but not actually do the render. For example if you want to export the scene but not render it you must turn on SuppressRendering and then call StillRender
|
virtual |
SuppressRendering can be used to suppress the render within a StillRender or InteractiveRender.
This is useful in cases where you want the representations mappers to be setup for rendering and have their data ready but not actually do the render. For example if you want to export the scene but not render it you must turn on SuppressRendering and then call StillRender
|
virtual |
SuppressRendering can be used to suppress the render within a StillRender or InteractiveRender.
This is useful in cases where you want the representations mappers to be setup for rendering and have their data ready but not actually do the render. For example if you want to export the scene but not render it you must turn on SuppressRendering and then call StillRender
|
virtual |
SuppressRendering can be used to suppress the render within a StillRender or InteractiveRender.
This is useful in cases where you want the representations mappers to be setup for rendering and have their data ready but not actually do the render. For example if you want to export the scene but not render it you must turn on SuppressRendering and then call StillRender
|
virtual |
Get/Set the reduction-factor to use when for StillRender().
This is typically set to 1, but in some cases with terrible connectivity or really large displays, one may want to use a sub-sampled image even for StillRender(). This is set it number of pixels to be sub-sampled by. Note that image reduction factors have no effect when in built-in mode.
|
virtual |
Get/Set the reduction-factor to use when for StillRender().
This is typically set to 1, but in some cases with terrible connectivity or really large displays, one may want to use a sub-sampled image even for StillRender(). This is set it number of pixels to be sub-sampled by. Note that image reduction factors have no effect when in built-in mode.
|
virtual |
Get/Set the reduction-factor to use when for InteractiveRender().
This is set it number of pixels to be sub-sampled by. Note that image reduction factors have no effect when in built-in mode.
|
virtual |
Get/Set the reduction-factor to use when for InteractiveRender().
This is set it number of pixels to be sub-sampled by. Note that image reduction factors have no effect when in built-in mode.
|
virtual |
Get/Set the data-size in megabytes above which remote-rendering should be used, if possible.
|
virtual |
Get/Set the data-size in megabytes above which remote-rendering should be used, if possible.
|
virtual |
Get/Set the data-size in megabytes above which LOD rendering should be used, if possible.
|
virtual |
Get/Set the data-size in megabytes above which LOD rendering should be used, if possible.
|
virtual |
Get/Set the LOD resolution.
This affects the size of the grid used for quadric clustering, for example. 1.0 implies maximum resolution while 0 implies minimum resolution.
|
virtual |
Get/Set the LOD resolution.
This affects the size of the grid used for quadric clustering, for example. 1.0 implies maximum resolution while 0 implies minimum resolution.
|
virtual |
When set to true, instead of using simplified geometry for LOD rendering, uses outline, if possible.
Note that not all representations support this mode and hence one may still see non-outline data being rendering when this flag is ON and LOD is being used.
|
virtual |
When set to true, instead of using simplified geometry for LOD rendering, uses outline, if possible.
Note that not all representations support this mode and hence one may still see non-outline data being rendering when this flag is ON and LOD is being used.
| void vtkPVRenderView::ConfigureCompressor | ( | const char * | configuration | ) |
Passes the compressor configuration to the client-server synchronizer, if any.
This affects the image compression used to relay images back to the client. See vtkPVClientServerSynchronizedRenderers::ConfigureCompressor() for details.
|
virtual |
Resets the clipping range.
One does not need to call this directly ever. It is called periodically by the vtkRenderer to reset the camera range.
| void vtkPVRenderView::SetUseLightKit | ( | bool | enable | ) |
Enable/Disable light kit.
|
virtual |
Enable/Disable light kit.
|
virtual |
Enable/Disable light kit.
|
virtual |
Enable/Disable light kit.
| void vtkPVRenderView::DeliverStreamedPieces | ( | unsigned int | size, |
| unsigned int * | representation_ids | ||
| ) |
|
static |
USE_LOD indicates if LOD is being used for the current render/update.
|
static |
Indicates the LOD resolution in REQUEST_UPDATE_LOD() pass.
|
static |
Indicates the LOD must use outline if possible in REQUEST_UPDATE_LOD() pass.
|
static |
Representation can publish this key in their REQUEST_INFORMATION() pass to indicate that the representation needs to disable IceT's empty image optimization.
This is typically only needed if a painter will make use of MPI global collective communications.
|
static |
Representation can publish this key in their REQUEST_INFORMATION() pass to indicate that the representation needs ordered compositing.
|
static |
Key used to pass meta-data about the view frustum in REQUEST_STREAMING_UPDATE() pass.
The value is a double vector with exactly 24 values.
|
static |
Streaming pass request.
|
static |
Pass to relay the streamed "piece" to the representations.
Make a selection.
This will result in setting up of this->LastSelection which can be accessed using GetLastSelection().
|
inline |
Make a selection.
This will result in setting up of this->LastSelection which can be accessed using GetLastSelection().
Definition at line 366 of file vtkPVRenderView.h.
Make a selection.
This will result in setting up of this->LastSelection which can be accessed using GetLastSelection().
|
inline |
Make a selection.
This will result in setting up of this->LastSelection which can be accessed using GetLastSelection().
Definition at line 372 of file vtkPVRenderView.h.
Make a selection.
This will result in setting up of this->LastSelection which can be accessed using GetLastSelection().
Make a selection with a polygon.
The polygon2DArray should contain the polygon points in display units of (x, y) tuples, and arrayLen is the total length of polygon2DArray. This will result in setting up of this->LastSelection which can be accessed using GetLastSelection().
Make a selection with a polygon.
The polygon2DArray should contain the polygon points in display units of (x, y) tuples, and arrayLen is the total length of polygon2DArray. This will result in setting up of this->LastSelection which can be accessed using GetLastSelection().
| void vtkPVRenderView::SelectPolygon | ( | int | field_association, |
| int * | polygon2DArray, | ||
| vtkIdType | arrayLen | ||
| ) |
Make a selection with a polygon.
The polygon2DArray should contain the polygon points in display units of (x, y) tuples, and arrayLen is the total length of polygon2DArray. This will result in setting up of this->LastSelection which can be accessed using GetLastSelection().
|
virtual |
Provides access to the last selection.
This is valid only on the client or driver node displaying the composited result.
|
virtual |
Set or get whether capture should be done as StillRender or InteractiveRender when capturing screenshots.
|
virtual |
Set or get whether capture should be done as StillRender or InteractiveRender when capturing screenshots.
|
virtual |
Set or get whether capture should be done as StillRender or InteractiveRender when capturing screenshots.
|
virtual |
Set or get whether capture should be done as StillRender or InteractiveRender when capturing screenshots.
|
virtual |
Returns if remote-rendering is possible on the current group of processes.
|
inline |
Returns if remote-rendering is possible on the current group of processes.
Definition at line 419 of file vtkPVRenderView.h.
| void vtkPVRenderView::NVPipeAvailableOn | ( | ) |
Determine if NVPipe is an available compressor option.
| void vtkPVRenderView::NVPipeAvailableOff | ( | ) |
Determine if NVPipe is an available compressor option.
|
virtual |
Returns true if the most recent render used LOD.
| void vtkPVRenderView::InvalidateCachedSelection | ( | ) |
Invalidates cached selection.
Called explicitly when view proxy thinks the cache may have become obsolete.
|
static |
Convenience methods used by representations to pass represented data.
If trueSize is non-zero, then that's the size used in making decisions about LOD/remote rendering etc and not the actual size of the dataset.
|
static |
Convenience methods used by representations to pass represented data.
If trueSize is non-zero, then that's the size used in making decisions about LOD/remote rendering etc and not the actual size of the dataset.
|
static |
Convenience methods used by representations to pass represented data.
If trueSize is non-zero, then that's the size used in making decisions about LOD/remote rendering etc and not the actual size of the dataset.
|
static |
Convenience methods used by representations to pass represented data.
If trueSize is non-zero, then that's the size used in making decisions about LOD/remote rendering etc and not the actual size of the dataset.
|
static |
Convenience methods used by representations to pass represented data.
If trueSize is non-zero, then that's the size used in making decisions about LOD/remote rendering etc and not the actual size of the dataset.
|
static |
Convenience methods used by representations to pass represented data.
If trueSize is non-zero, then that's the size used in making decisions about LOD/remote rendering etc and not the actual size of the dataset.
|
static |
Convenience methods used by representations to pass represented data.
If trueSize is non-zero, then that's the size used in making decisions about LOD/remote rendering etc and not the actual size of the dataset.
|
static |
Convenience methods used by representations to pass represented data.
If trueSize is non-zero, then that's the size used in making decisions about LOD/remote rendering etc and not the actual size of the dataset.
|
static |
Convenience methods used by representations to pass represented data.
If trueSize is non-zero, then that's the size used in making decisions about LOD/remote rendering etc and not the actual size of the dataset.
|
static |
Convenience methods used by representations to pass represented data.
If trueSize is non-zero, then that's the size used in making decisions about LOD/remote rendering etc and not the actual size of the dataset.
|
static |
OrderedCompositingConfiguration lets representations indicate to the view how the representation participates in data-redistribution necessary when ordered-compositing is being used.
These flags are meant to be combined together using bit-wise-OR.
If not specified, default is 0 i.e. the representation data will be left untouched. Except for trivial representations or representations that have their full rendering geometry available on all rendering ranks, this is not recommended.
DATA_IS_REDISTRIBUTABLE indicates that the view may redistribute the rendering data from this representation as needed. This is typical for representation rendering poly-data or unstructured grids.
USE_DATA_FOR_LOAD_BALANCING indicates that when building a sortable distribution for the data, it should use this representation data. If not set, the representation will not contribute to the algorithm that builds the kd-tree used to split data across rendering ranks.
USE_BOUNDS_FOR_REDISTRIBUTION may be used when the data is too heavy to move (i.e DATA_IS_REDISTRIBUTABLE is not true) and is already split across ranks in a sortable fashion. In that case, this indicates the view must use the spatial partitioning of this representation's data and move other data accordingly. This flag cannot be combined with DATA_IS_REDISTRIBUTABLE or USE_BOUNDS_FOR_REDISTRIBUTION.
| void vtkPVRenderView::SetMaxClipBounds | ( | double | bds[6] | ) |
Used by Cinema to enforce a consistent depth scaling.
Called with the global (visible and invisible) bounds at start of export.
| void vtkPVRenderView::SetLockBounds | ( | bool | nv | ) |
Used by Cinema to enforce a consistent viewpoint and depth scaling.
Prevents ParaView from changing depth scaling over course of an export.
|
virtual |
Used by Cinema to enforce a consistent viewpoint and depth scaling.
Prevents ParaView from changing depth scaling over course of an export.
|
static |
Requests the view to deliver the pieces produced by the repr to all processes after a gather to the root node to merge the datasets generated by each process.
|
static |
Requests the view to deliver the data to the client always.
This is essential for representation that render in the non-composited views e.g. the text-source representation. If SetDeliverToAllProcesses() is true, this is redundant. gather_before_delivery can be used to indicate if the data on the server-nodes must be gathered to the root node before shipping to the client. If gather_before_delivery is false, only the data from the root node will be sent to the client without any parallel communication.
|
static |
Some representation only work when remote rendering or local rendering.
Use this method in REQUEST_UPDATE() pass to tell the view if the representation requires a particular mode. Note, only use this to "require" a remote or local render. value == true indicates that the representation requires distributed rendering, value == false indicates the representation can only render property on the client or root node.
|
inlinestatic |
Some representation only work when remote rendering or local rendering.
Use this method in REQUEST_UPDATE() pass to tell the view if the representation requires a particular mode. Note, only use this to "require" a remote or local render. value == true indicates that the representation requires distributed rendering, value == false indicates the representation can only render property on the client or root node.
Definition at line 556 of file vtkPVRenderView.h.
|
static |
This is an temporary/experimental option and may be removed without notice.
This is intended to be used within some experimental representations that require that all data being moved around uses a specific mode rather than the one automatically determined based on the process type. Set flag to -1 to clear. The flag is cleared in every vtkPVRenderView::Update() call, hence a representation must set it in vtkPVView::REQUEST_UPDATE() pass if needed each time. Also note, if the value it set to non-negative and is not equal to vtkMPIMoveData::PASS_THROUGH, ordered compositing will also be disabled.
|
inline |
This is an temporary/experimental option and may be removed without notice.
This is intended to be used within some experimental representations that require that all data being moved around uses a specific mode rather than the one automatically determined based on the process type. Set flag to -1 to clear. The flag is cleared in every vtkPVRenderView::Update() call, hence a representation must set it in vtkPVView::REQUEST_UPDATE() pass if needed each time. Also note, if the value it set to non-negative and is not equal to vtkMPIMoveData::PASS_THROUGH, ordered compositing will also be disabled.
Definition at line 577 of file vtkPVRenderView.h.
|
inline |
This is an temporary/experimental option and may be removed without notice.
This is intended to be used within some experimental representations that require that all data being moved around uses a specific mode rather than the one automatically determined based on the process type. Set flag to -1 to clear. The flag is cleared in every vtkPVRenderView::Update() call, hence a representation must set it in vtkPVView::REQUEST_UPDATE() pass if needed each time. Also note, if the value it set to non-negative and is not equal to vtkMPIMoveData::PASS_THROUGH, ordered compositing will also be disabled.
Definition at line 578 of file vtkPVRenderView.h.
| int vtkPVRenderView::RegisterPropForHardwareSelection | ( | vtkPVDataRepresentation * | repr, |
| vtkProp * | prop | ||
| ) |
Representations that support hardware (render-buffer based) selection, should register the prop that they use for selection rendering.
They can do that in the vtkPVDataRepresentation::AddToView() implementation.
| void vtkPVRenderView::UnRegisterPropForHardwareSelection | ( | vtkPVDataRepresentation * | repr, |
| vtkProp * | prop | ||
| ) |
Representations that support hardware (render-buffer based) selection, should register the prop that they use for selection rendering.
They can do that in the vtkPVDataRepresentation::AddToView() implementation.
| void vtkPVRenderView::SetShowAnnotation | ( | bool | val | ) |
Enable/disable showing of annotation for developers.
|
virtual |
Enable/disable showing of annotation for developers.
Set color of annotation text for developers.
|
virtual |
Set the vtkPVGridAxes3DActor to use for the view.
Reimplemented in vtkPVOrthographicSliceView.
|
virtual |
Set the vtkLegendScaleActor to use for the view.
|
virtual |
Set the vtkPolarAxesActor to use for the view.
|
virtual |
Forwarded to orientation axes widget.
|
virtual |
Forwarded to orientation axes widget.
Forwarded to orientation axes widget.
Forwarded to orientation axes widget.
Forwarded to orientation axes widget.
Forwarded to orientation axes widget.
Forwarded to orientation axes widget.
| void vtkPVRenderView::SetOrientationAxesXVisibility | ( | bool | vis | ) |
Forwarded to orientation axes widget.
| void vtkPVRenderView::SetOrientationAxesYVisibility | ( | bool | vis | ) |
Forwarded to orientation axes widget.
| void vtkPVRenderView::SetOrientationAxesZVisibility | ( | bool | vis | ) |
Forwarded to orientation axes widget.
| void vtkPVRenderView::SetOrientationAxesXLabelText | ( | const char * | text | ) |
Forwarded to orientation axes widget.
| void vtkPVRenderView::SetOrientationAxesYLabelText | ( | const char * | text | ) |
Forwarded to orientation axes widget.
| void vtkPVRenderView::SetOrientationAxesZLabelText | ( | const char * | text | ) |
Forwarded to orientation axes widget.
| void vtkPVRenderView::SetCameraOrientationWidgetVisibility | ( | bool | visible | ) |
Forwarded to camera orientation widget.
| void vtkPVRenderView::SetCameraOrientationWidgetSize | ( | int | size | ) |
Forwarded to camera orientation widget.
| void vtkPVRenderView::SetCameraOrientationWidgetPadding | ( | int | padding[2] | ) |
Forwarded to camera orientation widget.
| void vtkPVRenderView::SetCameraOrientationWidgetAnchor | ( | int | anchor | ) |
Forwarded to camera orientation widget.
|
virtual |
Forwarded to center axes.
Reimplemented in vtkPVOrthographicSliceView.
Forward to vtkPVInteractorStyle instances.
Reimplemented in vtkPVOrthographicSliceView.
|
virtual |
Forward to vtkPVInteractorStyle instances.
Reimplemented in vtkPVOrthographicSliceView.
| void vtkPVRenderView::SetKeyLightWarmth | ( | double | val | ) |
Forward to vtkLightKit.
| void vtkPVRenderView::SetKeyLightIntensity | ( | double | val | ) |
Forward to vtkLightKit.
| void vtkPVRenderView::SetKeyLightElevation | ( | double | val | ) |
Forward to vtkLightKit.
| void vtkPVRenderView::SetKeyLightAzimuth | ( | double | val | ) |
Forward to vtkLightKit.
| void vtkPVRenderView::SetFillLightWarmth | ( | double | val | ) |
Forward to vtkLightKit.
| void vtkPVRenderView::SetKeyToFillRatio | ( | double | val | ) |
Forward to vtkLightKit.
| void vtkPVRenderView::SetFillLightElevation | ( | double | val | ) |
Forward to vtkLightKit.
| void vtkPVRenderView::SetFillLightAzimuth | ( | double | val | ) |
Forward to vtkLightKit.
| void vtkPVRenderView::SetBackLightWarmth | ( | double | val | ) |
Forward to vtkLightKit.
| void vtkPVRenderView::SetKeyToBackRatio | ( | double | val | ) |
Forward to vtkLightKit.
| void vtkPVRenderView::SetBackLightElevation | ( | double | val | ) |
Forward to vtkLightKit.
| void vtkPVRenderView::SetBackLightAzimuth | ( | double | val | ) |
Forward to vtkLightKit.
| void vtkPVRenderView::SetHeadLightWarmth | ( | double | val | ) |
Forward to vtkLightKit.
| void vtkPVRenderView::SetKeyToHeadRatio | ( | double | val | ) |
Forward to vtkLightKit.
| void vtkPVRenderView::SetMaintainLuminance | ( | int | val | ) |
Forward to vtkLightKit.
|
virtual |
Forward to 3D renderer.
|
virtual |
Forward to 3D renderer.
|
virtual |
Forward to 3D renderer.
|
virtual |
Forward to 3D renderer.
|
virtual |
Forward to 3D renderer.
Reimplemented in vtkPVOrthographicSliceView.
|
virtual |
When set, background color and mode will be obtained from vtkPVRenderViewSettings.
|
virtual |
When set, background color and mode will be obtained from vtkPVRenderViewSettings.
|
virtual |
API for background color selection.
API for background color selection.
|
virtual |
API for background color selection.
|
virtual |
API for background color selection.
API for background color selection.
|
virtual |
API for background color selection.
API for background color selection.
|
virtual |
API for background color selection.
|
virtual |
API for background color selection.
API for background color selection.
|
virtual |
API for background color selection.
|
virtual |
API for background color selection.
Entry point for environmental backgrounds.
Entry point for environmental backgrounds.
|
virtual |
Entry point for environmental backgrounds.
|
virtual |
Entry point for environmental backgrounds.
|
virtual |
Entry point for environmental backgrounds.
|
virtual |
Entry point for environmental backgrounds.
| void vtkPVRenderView::AddLight | ( | vtkLight * | ) |
Entry point for dynamic lights.
| void vtkPVRenderView::RemoveLight | ( | vtkLight * | ) |
Entry point for dynamic lights.
| void vtkPVRenderView::SetStereoCapableWindow | ( | int | val | ) |
Forward to vtkRenderWindow.
| void vtkPVRenderView::SetStereoRender | ( | int | val | ) |
Forward to vtkRenderWindow.
|
virtual |
Forward to vtkRenderWindow.
|
virtual |
Forward to vtkRenderWindow.
| void vtkPVRenderView::SetMultiSamples | ( | int | val | ) |
Forward to vtkRenderWindow.
| void vtkPVRenderView::SetAlphaBitPlanes | ( | int | val | ) |
Forward to vtkRenderWindow.
| void vtkPVRenderView::SetStencilCapable | ( | int | val | ) |
Forward to vtkRenderWindow.
Forwarded to vtkPVInteractorStyle if present on local processes.
Forwarded to vtkPVInteractorStyle if present on local processes.
| void vtkPVRenderView::SetCameraManipulators | ( | vtkPVInteractorStyle * | style, |
| const int | manipulators[9] | ||
| ) |
Forwarded to vtkPVInteractorStyle if present on local processes.
|
virtual |
Forwarded to vtkPVInteractorStyle if present on local processes.
|
virtual |
Forwarded to vtkPVInteractorStyle if present on local processes.
|
virtual |
Forwarded to vtkPVInteractorStyle if present on local processes.
|
virtual |
Forwarded to vtkPVInteractorStyle if present on local processes.
|
virtual |
Synchronizes bounds information on all nodes and reset camera clipping planes.
|
overridevirtual |
Overridden to synchronize information among processes whenever data changes.
The vtkSMViewProxy ensures that this method is called only when something has changed on the view-proxy or one of its representations or their inputs. Hence it's okay to do some extra inter-process communication here.
Reimplemented from vtkView.
|
virtual |
Asks representations to update their LOD geometries.
|
virtual |
Returns whether the view will use LOD rendering for the next InteractiveRender() call based on the geometry sizes determined by the most recent call to Update().
|
virtual |
Returns whether the view will use distributed rendering for the next full-resolution render.
This uses the full resolution geometry sizes as determined by the most recent call to Update.
|
virtual |
Returns whether the view will use distributed rendering for the next low-resolution render.
This uses the low-resolution (or LOD) geometry sizes as determined by the most recent call to UpdateLOD.
|
virtual |
Returns the processes (vtkPVSession::ServerFlags) that are to be involved in the next StillRender() call based on the decisions made during the most recent Update().
|
virtual |
Returns the processes (vtkPVSession::ServerFlags) that are to be involved in the next InteractiveRender() call based on the decisions made during the most recent Update() and UpdateLOD().
| int vtkPVRenderView::GetDataDistributionMode | ( | bool | low_res | ) |
Returns the data distribution mode to use.
|
overridevirtual |
Called on all processes to request data-delivery for the list of representations.
Note this method has to be called on all processes or it may lead to deadlock.
Reimplemented from vtkPVView.
| bool vtkPVRenderView::GetUseOrderedCompositing | ( | ) |
Returns true when ordered compositing is needed on the current group of processes.
Note that unlike most other functions, this may return different values on different processes e.g.
| bool vtkPVRenderView::GetRenderEmptyImages | ( | ) |
Returns true when the compositor should not use the empty images optimization.
|
virtual |
Enable/disable FXAA antialiasing.
|
virtual |
Enable/disable FXAA antialiasing.
| void vtkPVRenderView::SetFXAARelativeContrastThreshold | ( | double | val | ) |
FXAA tunable parameters.
See vtkFXAAOptions for details.
| void vtkPVRenderView::SetFXAAHardContrastThreshold | ( | double | val | ) |
FXAA tunable parameters.
See vtkFXAAOptions for details.
| void vtkPVRenderView::SetFXAASubpixelBlendLimit | ( | double | val | ) |
FXAA tunable parameters.
See vtkFXAAOptions for details.
| void vtkPVRenderView::SetFXAASubpixelContrastThreshold | ( | double | val | ) |
FXAA tunable parameters.
See vtkFXAAOptions for details.
| void vtkPVRenderView::SetFXAAUseHighQualityEndpoints | ( | bool | val | ) |
FXAA tunable parameters.
See vtkFXAAOptions for details.
| void vtkPVRenderView::SetFXAAEndpointSearchIterations | ( | int | val | ) |
FXAA tunable parameters.
See vtkFXAAOptions for details.
| void vtkPVRenderView::SetUseToneMapping | ( | bool | v | ) |
Tone Mapping options.
|
virtual |
Tone Mapping options.
| void vtkPVRenderView::SetToneMappingType | ( | int | ) |
Tone Mapping options.
| void vtkPVRenderView::SetExposure | ( | double | ) |
Tone Mapping options.
| void vtkPVRenderView::SetContrast | ( | double | ) |
Tone Mapping options.
| void vtkPVRenderView::SetShoulder | ( | double | ) |
Tone Mapping options.
| void vtkPVRenderView::SetMidIn | ( | double | ) |
Tone Mapping options.
| void vtkPVRenderView::SetMidOut | ( | double | ) |
Tone Mapping options.
| void vtkPVRenderView::SetHdrMax | ( | double | ) |
Tone Mapping options.
| void vtkPVRenderView::SetUseACES | ( | bool | ) |
Tone Mapping options.
| void vtkPVRenderView::SetGenericFilmicPresets | ( | int | t | ) |
Tone Mapping options.
|
virtual |
SSAO options.
|
virtual |
SSAO options.
|
virtual |
SSAO options.
|
virtual |
SSAO options.
|
virtual |
SSAO options.
|
virtual |
SSAO options.
|
virtual |
SSAO options.
| void vtkPVRenderView::CopyViewUpdateOptions | ( | vtkPVRenderView * | otherView | ) |
Copy internal fields that are used for rendering decision such as remote/local rendering, composite and so on.
This method was introduced for the quad view so internal views could use the decision that were made in the main view.
| void vtkPVRenderView::AddPropToRenderer | ( | vtkProp * | prop | ) |
Add props directly to the view.
| void vtkPVRenderView::RemovePropFromRenderer | ( | vtkProp * | prop | ) |
Add props directly to the view.
| bool vtkPVRenderView::BeginValuePassForRendering | ( | int | fieldAssociation, |
| const char * | arrayName, | ||
| int | component | ||
| ) |
Experimental API to grab re-colorable images.
Between BeginValuePassForRendering and EndValuePassForRendering calls, all renders will end up using vtkValuePass for rendering instead of the standard rendering passes that generate results on screen.
GrabValuePassResult must be called between BeginValuePassForRendering and EndValuePassForRendering. Returns the vtkFloatArray grabbed by vtkValuePass.
This API is not intended for remote-rendering use-cases. Thus only supported in client-only and pvbatch (or in situ) cases. That's the reason why we are exposing this directly on the vtkPVRenderView rather accessing it via a proxy.
| void vtkPVRenderView::EndValuePassForRendering | ( | ) |
Experimental API to grab re-colorable images.
Between BeginValuePassForRendering and EndValuePassForRendering calls, all renders will end up using vtkValuePass for rendering instead of the standard rendering passes that generate results on screen.
GrabValuePassResult must be called between BeginValuePassForRendering and EndValuePassForRendering. Returns the vtkFloatArray grabbed by vtkValuePass.
This API is not intended for remote-rendering use-cases. Thus only supported in client-only and pvbatch (or in situ) cases. That's the reason why we are exposing this directly on the vtkPVRenderView rather accessing it via a proxy.
| vtkSmartPointer<vtkFloatArray> vtkPVRenderView::GrabValuePassResult | ( | ) |
Experimental API to grab re-colorable images.
Between BeginValuePassForRendering and EndValuePassForRendering calls, all renders will end up using vtkValuePass for rendering instead of the standard rendering passes that generate results on screen.
GrabValuePassResult must be called between BeginValuePassForRendering and EndValuePassForRendering. Returns the vtkFloatArray grabbed by vtkValuePass.
This API is not intended for remote-rendering use-cases. Thus only supported in client-only and pvbatch (or in situ) cases. That's the reason why we are exposing this directly on the vtkPVRenderView rather accessing it via a proxy.
| void vtkPVRenderView::CaptureZBuffer | ( | ) |
Access to the Z buffer.
| vtkFloatArray* vtkPVRenderView::GetCapturedZBuffer | ( | ) |
Access to the Z buffer.
| void vtkPVRenderView::SetEnableOSPRay | ( | bool | ) |
Switches between rasterization and ray tracing.
| bool vtkPVRenderView::GetEnableOSPRay | ( | ) |
Switches between rasterization and ray tracing.
| void vtkPVRenderView::SetShadows | ( | bool | ) |
Controls whether OSPRay sends casts shadow rays or not.
| bool vtkPVRenderView::GetShadows | ( | ) |
Controls whether OSPRay sends casts shadow rays or not.
| void vtkPVRenderView::SetAmbientOcclusionSamples | ( | int | ) |
Sets the number of occlusion query rays that OSPRay sends at each intersection.
| int vtkPVRenderView::GetAmbientOcclusionSamples | ( | ) |
Sets the number of occlusion query rays that OSPRay sends at each intersection.
| void vtkPVRenderView::SetRouletteDepth | ( | int | ) |
Sets the depth of monte carlo samples on the path tracer.
| int vtkPVRenderView::GetRouletteDepth | ( | ) |
Sets the depth of monte carlo samples on the path tracer.
| void vtkPVRenderView::SetSamplesPerPixel | ( | int | ) |
Set the number of primary rays that OSPRay shoots per pixel.
| int vtkPVRenderView::GetSamplesPerPixel | ( | ) |
Set the number of primary rays that OSPRay shoots per pixel.
| void vtkPVRenderView::SetMaxFrames | ( | int | ) |
Set the number of render passes OSPRay takes to accumulate subsampled color results.
| int vtkPVRenderView::GetMaxFrames | ( | ) |
Set the number of render passes OSPRay takes to accumulate subsampled color results.
| bool vtkPVRenderView::GetOSPRayContinueStreaming | ( | ) |
Has OSPRay reached the max frames?
| void vtkPVRenderView::SetDenoise | ( | bool | ) |
Controls whether to use image denoising to improve appearance.
| bool vtkPVRenderView::GetDenoise | ( | ) |
Controls whether to use image denoising to improve appearance.
| void vtkPVRenderView::SetLightScale | ( | double | ) |
Dimish or Amplify all lights in the scene.
| double vtkPVRenderView::GetLightScale | ( | ) |
Dimish or Amplify all lights in the scene.
| void vtkPVRenderView::SetOSPRayRendererType | ( | std::string | ) |
Set the OSPRay renderer to use.
May be either scivis (default) or pathtracer.
Control of background orientation for OSPRay.
Control of background orientation for OSPRay.
|
virtual |
For OSPRay, set the library of materials.
|
overridevirtual |
| void vtkPVRenderView::SetTimeCacheSize | ( | int | ) |
Set the size of OSPRay's temporal cache.
| int vtkPVRenderView::GetTimeCacheSize | ( | ) |
Set the size of OSPRay's temporal cache.
|
static |
DiscreteCameras are a collection of cameras when specified, forces the view to only interact to a camera in the collection.
In vtkPVView::REQUEST_UPDATE() pass, representations may request the view to use discrete cameras by providing a vtkPVCameraCollection to the view. Since multiple representations may be visible in the view, it's up to the representations how to handle multiple representations providing different styles.
When set, on each render, vtkPVRenderView will try to update the current camera to match a camera in the collection. During interacting, however, the snapping to a camera in the collection is only done when the snapped to camera is different from the previous. This avoids side effects on camera manipulators that simply update existing camera positions during interaction.
|
static |
DiscreteCameras are a collection of cameras when specified, forces the view to only interact to a camera in the collection.
In vtkPVView::REQUEST_UPDATE() pass, representations may request the view to use discrete cameras by providing a vtkPVCameraCollection to the view. Since multiple representations may be visible in the view, it's up to the representations how to handle multiple representations providing different styles.
When set, on each render, vtkPVRenderView will try to update the current camera to match a camera in the collection. During interacting, however, the snapping to a camera in the collection is only done when the snapped to camera is different from the previous. This avoids side effects on camera manipulators that simply update existing camera positions during interaction.
|
virtual |
Overridden to scale the OrientationWidget appropriately.
Reimplemented from vtkPVView.
This is used by vtkPVHardwareSelector to synchronize element ids between all ranks involved in selection.
| void vtkPVRenderView::SetHardwareSelector | ( | vtkPVHardwareSelector * | selector | ) |
|
protectedvirtual |
Actual render method.
|
inlineprotectedvirtual |
Called just before the local process renders.
This is only called on the nodes where the rendering is going to happen.
Reimplemented in vtkPVOrthographicSliceView, and vtkPVMultiSliceView.
Definition at line 1130 of file vtkPVRenderView.h.
|
protected |
Returns true if distributed rendering should be used based on the geometry size.
using_lod will be true if this method is called to determine distributed rendering status for renders using lower LOD i.e when called in UpdateLOD().
|
protected |
Returns true if LOD rendering should be used based on the geometry size.
|
protected |
Returns true if the local process is invovled in rendering composited geometry i.e.
geometry rendered in view that is composited together.
|
protected |
Set the last selection object.
|
protectedvirtual |
Updates CenterAxes's scale and position.
Reimplemented in vtkPVOrthographicSliceView.
|
protected |
Returns true if the local process is doing to do actual render or displaying an image in a viewport.
|
protected |
In multi-clients mode, ensures that all processes are in the same "state" as far as the view is concerned.
Returns false if that's not the case.
|
protected |
Synchronizes remote-rendering related parameters for collaborative rendering in multi-clients mode.
|
protectedvirtual |
Method to build annotation text to annotate the view with runtime information.
|
protectedvirtual |
SynchronizationCounter is used in multi-clients mode to ensure that the views on two different clients are in the same state as the server side.
|
protectedvirtual |
Returns true is currently generating a selection.
|
protectedvirtual |
Prepare for selection.
Returns false if it is currently generating a selection.
|
protectedvirtual |
Post process after selection.
|
protectedvirtual |
Updates background color.
If no renderer is specified, then the default renderer returned by GetRenderer is used.
Reimplemented in vtkPVOrthographicSliceView.
|
protected |
Configure texture based on scalar type.
|
protectedvirtual |
Set the 3D renderer to use within the render view.
This function modifies the input renderer in order to be usable by the render view.
| double vtkPVRenderView::LastRepresentationVisibleBounds[6] |
Compute and reduce the visible bounds of the provided representation.
Uses LastRepresentationVisibleBounds to store the result until the next call.
Definition at line 182 of file vtkPVRenderView.h.
|
protected |
Definition at line 1230 of file vtkPVRenderView.h.
|
protected |
Definition at line 1231 of file vtkPVRenderView.h.
|
protected |
Definition at line 1232 of file vtkPVRenderView.h.
|
protected |
Definition at line 1233 of file vtkPVRenderView.h.
|
protected |
Definition at line 1234 of file vtkPVRenderView.h.
|
protected |
Definition at line 1235 of file vtkPVRenderView.h.
|
protected |
Definition at line 1236 of file vtkPVRenderView.h.
|
protected |
Definition at line 1237 of file vtkPVRenderView.h.
|
protected |
Definition at line 1238 of file vtkPVRenderView.h.
|
protected |
Definition at line 1239 of file vtkPVRenderView.h.
|
protected |
Definition at line 1240 of file vtkPVRenderView.h.
|
protected |
Definition at line 1241 of file vtkPVRenderView.h.
|
protected |
Definition at line 1242 of file vtkPVRenderView.h.
|
protected |
Definition at line 1243 of file vtkPVRenderView.h.
|
protected |
Definition at line 1244 of file vtkPVRenderView.h.
|
protected |
Definition at line 1245 of file vtkPVRenderView.h.
|
protected |
Definition at line 1246 of file vtkPVRenderView.h.
|
protected |
Definition at line 1248 of file vtkPVRenderView.h.
|
protected |
Definition at line 1249 of file vtkPVRenderView.h.
|
protected |
Definition at line 1250 of file vtkPVRenderView.h.
|
protected |
Definition at line 1251 of file vtkPVRenderView.h.
|
protected |
Definition at line 1252 of file vtkPVRenderView.h.
|
protected |
Definition at line 1261 of file vtkPVRenderView.h.
|
protected |
Definition at line 1264 of file vtkPVRenderView.h.
|
protected |
Definition at line 1265 of file vtkPVRenderView.h.
|
protected |
Definition at line 1267 of file vtkPVRenderView.h.
|
protected |
Definition at line 1270 of file vtkPVRenderView.h.
|
protected |
Definition at line 1272 of file vtkPVRenderView.h.
|
protected |
Definition at line 1276 of file vtkPVRenderView.h.
|
protected |
Definition at line 1279 of file vtkPVRenderView.h.
|
protected |
Definition at line 1280 of file vtkPVRenderView.h.
|
protected |
Definition at line 1281 of file vtkPVRenderView.h.
|
protected |
Definition at line 1283 of file vtkPVRenderView.h.
|
protected |
Definition at line 1284 of file vtkPVRenderView.h.
|
protected |
Definition at line 1285 of file vtkPVRenderView.h.
|
protected |
Definition at line 1287 of file vtkPVRenderView.h.
|
protected |
Definition at line 1288 of file vtkPVRenderView.h.
|
protected |
Definition at line 1290 of file vtkPVRenderView.h.
|
protected |
Definition at line 1292 of file vtkPVRenderView.h.
|
protected |
Definition at line 1293 of file vtkPVRenderView.h.
|
protected |
Definition at line 1294 of file vtkPVRenderView.h.
|
protected |
Definition at line 1295 of file vtkPVRenderView.h.
|
protected |
Definition at line 1296 of file vtkPVRenderView.h.
|
protected |
Definition at line 1297 of file vtkPVRenderView.h.
|
protected |
Definition at line 1299 of file vtkPVRenderView.h.
|
protected |
Definition at line 1300 of file vtkPVRenderView.h.
|
protected |
Definition at line 1302 of file vtkPVRenderView.h.
|
protected |
Definition at line 1303 of file vtkPVRenderView.h.
|
protected |
Definition at line 1304 of file vtkPVRenderView.h.
|
protected |
Definition at line 1305 of file vtkPVRenderView.h.
|
protected |
Definition at line 1306 of file vtkPVRenderView.h.
|
protected |
Definition at line 1308 of file vtkPVRenderView.h.
|
protected |
Definition at line 1309 of file vtkPVRenderView.h.
|
protected |
Keeps track of the time when the priority-queue for streaming was generated.
Definition at line 1315 of file vtkPVRenderView.h.
|
protected |
Definition at line 1317 of file vtkPVRenderView.h.
1.8.13 on Tue Oct 1 2024
